AutoVue EDA Professional概述 實現對PCB（布局和原理圖）、Office文檔和圖像文件的通用訪問 通過前期溝通來識別和解決設計問題，最大限度地減少昂貴的板旋轉 加快文件審查和審批，并通過內置數字注釋簡化工程變更管理 簡化PCB測試工程和制造裝配流程 可以與企業應用程序（如產品生命周期管理系統）進行整合

特征與優勢

• View all relevant EDA formats including: Artwork formats, PCB / IC Layouts, Schematics and Manufacturing formats
• Highlight the selected entity and dim the rest of the board for easier viewing
• Minimum distance tool for measuring the proximity of nets, pins and pads to one another from edge of net or components
• Generate BOMs for multi-page schematics and export results
• Select all net instances when nets span multiple pages.
• Cross Probe between a PCB Layout and related schematics. Select a net or component in a Schematic and it is located and highlighted in the Layout or vice versa.
• Verify Design: Test for manufacturability or design violations (ie: pad/trace/component clearances, drill hole size, via counts, net width/length, short circuits, unrouted nets, empty nets, unconnected pins ...) by setting multiple tolerances/constraints. Export the detected violations and share with others to shorten the overall design cycle and accelerate production.
• Select filters to hide/show entities based on type.
• Dynamic Layer control allows you to toggle layers on and off at a single click of the mouse.
• Highlight and Zoom to selected Nets or Components.
• Control layer properties including visibility, printability, order and color at a click of the mouse. Users can access pre-defined layer sets (views) or define their own.
• Generate 3D models of a PCB from the native ECAD data.
• Full Search and Highlight for multiple Components and Nets based on a variety of attributes, keywords and values. Search for Nets, Components, Pins, Vias, Devices or Parts. Export these custom lists in a variety of formats.
• Access the full, embedded intelligence in a PCB with attribute querying for Traces, Nets, Components, Inserts and Geometry Library Objects.
• Take precise measurements using the snapping feature: position the cursor precisely on the endpoint / midpoint of a line, the intersection of two nets, the center of a circle, or on any pin / via / symbol origin.
• Masking feature makes selected components stand out from their surroundings on the PCB for ease of visualization.
• Highlight nets. Trace the path of a net or signal through various PCB layers and across multiple schematic pages.
