protected void button1_Click (object sender, System.EventArgs e)
{
    try
    {
         // Bind to a DataSet object
         LL.SetDataBinding(myDataSet, "Orders");

         // Set Properties
         LL.AutoDesignerFile  = "subreport.lst";
         LL.AutoProjectType  = LlProject.List;
         LL.AutoDialogTitle  = "Sample";
         LL.AutoShowSelectFile = true;

         // Call the Designer
         LL.Design();
    }
   // Catch Exceptions:
   catch (Exception LlException)
   {
         MessageBox.Show("Information: " +
                 LlException.Message,"Information",
                 MessageBox.IconInformation | MessageBox.OK);
    }
}

{Start the Designer}
procedure TForm1.DesignButtonClick(Sender: TObject);
begin
     //Assign data source
     LL.DataSource := dsCustomers;

     //Pass customer data as fields
     LL.AutoMasterMode := mmAsFields;

     //Set the default project name
     LL.AutoDesignerFile := 'subrep.lst';

     //Switch print mode to preview
     LL.AutoDestination := adPreview;

     //Call Designer
     LL.AutoDesign('Invoice List', '');
end;

 // Define special fields

normal text field:
LlDefineFieldExt(job, "Text", "Testtext",LL_TEXT, NULL);

// Footer field, i.e. numeric:
LlDefineFieldExt(job, "Subtotal", "12.34",
  LL_NUMERIC | LL_TABLE_FOOTERFIELD, NULL);

// Barcode field:
LlDefineFieldExt(job, "BC_EAN_128", "123456789abcd",
  LL_BARCODE_EAN128, NULL);

// Variable graphics by file name:
LlDefineFieldExt(job, "Regular Graphic","sunny.bmp",
  LL_DRAWING, NULL);

// File open dialog with sketch:
LlSelectFileDlgTitleEx(job, hWnd, "File open",
  LL_PROJECT_LIST, szFile,sizeof(szFile), NULL);

// Remove a certain menu command from the Designer:
LlDesignerProhibitAction(job, 211);

// Start the Designer with the above fields:
LlDefineLayout(job, hWnd, "Title", LL_PROJECT_LIST, szFile);

Private SubButtonDesign_Click()
  'Start the Designer with the title "Invoice" and the file "invoice.rpt":
   ListLabel1.Design(0, hWnd, "Invoice", LL_PROJECT_LIST, "invoice.rpt", 1)
End Sub

For data definition the event ListLabel1_CmndDefineFields is used.

 private void button2_Click(object sender, System.EventArgs e)
{
     try
     {
          // Bind to a DataSet object
          LL.SetDataBinding(myDataSet, ";Orders");

          // Set Properties
          LL.AutoDesignerFile  = "subreport.lst";
          LL.AutoProjectType  = LlProject.List;
          LL.AutoDialogTitle  = "Example";
          LL.AutoShowSelectFile = true;

          // Start Print
          LL.Print();
     }
     // Catch Exceptions:
    catch (Exception LlException)
    {
           MessageBox.Show("Information: " +
                    LlException.Message,"Information",
                    MessageBox.IconInformation | MessageBox.OK);
    }
}

{Printing}
procedure TForm1.PrintButtonClick(Sender: TObject);
begin
     //Assign data source
     LL.DataSource := dsCustomers;

     //Pass customer data as fields
     LL.AutoMasterMode := mmAsFields;

     //Set the default project name
     LL.AutoDesignerFile := 'subrep.lst';

     //Switch print mode to preview
     LL.AutoDestination := adPreview;

     //Print
     LL.AutoDesign('Invoice List', ,);
end;

//=====================================
void CMainFrame::DoLabelPrint()
//=====================================
{
  // Define special fields, regular text field:
  LLDefineFieldExt(job, "Text", "Testtext",LL_TEXT, NULL);

  // Numeric field:
  LLDefineVariableExt(job, "Subtotal", "12.34",
    LL_NUMERIC | LL_NUMERIC, NULL);

  // Barcode field:
  LLDefineVariableExt(job, "BC_EAN_128", "123456789abcd",
    LL_BARCODE_EAN128, NULL);

  // Variable graphic by file name:
  LLDefineVariableExt(job, "Graphic","sunny.bmp", LL_DRAWING, NULL);

  // Start printing:
  LlPrintWithBoxStart(job, LL_PROJECT_LABEL, szFile,
    LL_PRINT_EXPORT, LL_BOXTYPE_BRIDGEMETER, hWnd, "Printing...");

  //Print label:
  nErrorValue = LlPrint(job);

  // End printing:
  LlPrintEnd(job,0);
}

Private Sub ButtonPrint_Click()

  'Print the project "test.rpt" on the printer:
  Data1.Recordset.MoveFirst
  ListLabel1.Print(0, LL_PROJECT_LIST, "test.lst",_
    True, LL_PRINT_NORMAL,_
    LL_BOXTYPE_NORMALWAIT, hWnd,_
    "Print, True, Environ$("temp"))

End Sub

Private Sub ListLabel1_CmndDefineFields(ByVal nUserData As Long,
  ByVal bDummy As Long, nProgressInPerc As Long, pbLastRec As Long)

  'This event is called by the commands Print and Design.
  'It is called for each record to declare the fields and
  'their contents to List & Label.
  'Repeat for all fields of a 'record:
  For i = 0 To Form1.Data1.Recordset.Fields.Count - 1
    content$ = Data1.Recordset.Fields(i)
    nRet = ListLabel1.LlDefineFieldExt _
      (Data1.Recordset.Fields(i).Name,_
      content$, LL_TEXT)
  Next i
  'Skip to next record:
  Form1.Data1.Recordset.MoveNext
  'Stop printing of last record is reached:
  If Form1.Data1.Recordset.EOF = True Then
    pbLastRec = 1
  End If

End Sub

 protected void button1_Click (object sender, System.EventArgs e)
{
    try
    {
         // Bind to a DataSet object
         LL.SetDataBinding(myDataSet, "Orders");

         // Set Properties
         LL.AutoDesignerFile  = "subreport.lst";
         LL.AutoProjectType  = LlProject.List;
         LL.AutoDialogTitle  = "Sample";
         LL.AutoShowSelectFile = true;

         // Call the Designer
         LL.Design();
    }
   // Catch Exceptions:
   catch (Exception LlException)
   {
         MessageBox.Show("Information: " +
                 LlException.Message,"Information",
                 MessageBox.IconInformation | MessageBox.OK);
    }
}

{Start the Designer}
procedure TForm1.DesignButtonClick(Sender: TObject);
begin
     //Assign data source
     LL.DataSource := dsCustomers;

     //Pass customer data as fields
     LL.AutoMasterMode := mmAsFields;

     //Set the default project name
     LL.AutoDesignerFile := 'subrep.lst';

     //Switch print mode to preview
     LL.AutoDestination := adPreview;

     //Call Designer
     LL.AutoDesign('Invoice List', '');
end;

 // Define special fields

normal text field:
LlDefineFieldExt(job, "Text", "Testtext",LL_TEXT, NULL);

// Footer field, i.e. numeric:
LlDefineFieldExt(job, "Subtotal", "12.34",
  LL_NUMERIC | LL_TABLE_FOOTERFIELD, NULL);

// Barcode field:
LlDefineFieldExt(job, "BC_EAN_128", "123456789abcd",
  LL_BARCODE_EAN128, NULL);

// Variable graphics by file name:
LlDefineFieldExt(job, "Regular Graphic","sunny.bmp",
  LL_DRAWING, NULL);

// File open dialog with sketch:
LlSelectFileDlgTitleEx(job, hWnd, "File open",
  LL_PROJECT_LIST, szFile,sizeof(szFile), NULL);

// Remove a certain menu command from the Designer:
LlDesignerProhibitAction(job, 211);

// Start the Designer with the above fields:
LlDefineLayout(job, hWnd, "Title", LL_PROJECT_LIST, szFile);

Private SubButtonDesign_Click()
  'Start the Designer with the title "Invoice" and the file "invoice.rpt":
   ListLabel1.Design(0, hWnd, "Invoice", LL_PROJECT_LIST, "invoice.rpt", 1)
End Sub

For data definition the event ListLabel1_CmndDefineFields is used.

 private void button2_Click(object sender, System.EventArgs e)
{
     try
     {
          // Bind to a DataSet object
          LL.SetDataBinding(myDataSet, "Orders");

          // Set Properties
          LL.AutoDesignerFile  = "subreport.lst";
          LL.AutoProjectType  = LlProject.List;
          LL.AutoDialogTitle  = "Example";
          LL.AutoShowSelectFile = true;

          // Start Print
          LL.Print();
     }
     // Catch Exceptions:
    catch (Exception LlException)
    {
           MessageBox.Show("Information: " +
                    LlException.Message,"Information",
                    MessageBox.IconInformation | MessageBox.OK);
    }
}

{Printing}
procedure TForm1.PrintButtonClick(Sender: TObject);
begin
     //Assign data source
     LL.DataSource := dsCustomers;

     //Pass customer data as fields
     LL.AutoMasterMode := mmAsFields;

     //Set the default project name
     LL.AutoDesignerFile := 'subrep.lst';

     //Switch print mode to preview
    ; LL.AutoDestination := adPreview;

     //Print
     LL.AutoDesign('Invoice List', ,);
end;

//=====================================
void CMainFrame::DoLabelPrint()
//=====================================
{
  // Define special fields, regular text field:
  LLDefineFieldExt(job, "Text", "Testtext",LL_TEXT, NULL);

  // Numeric field:
  LLDefineVariableExt(job, "Subtotal", "12.34",
    LL_NUMERIC | LL_NUMERIC, NULL);

  // Barcode field:
  LLDefineVariableExt(job, "BC_EAN_128", "123456789abcd",
    LL_BARCODE_EAN128, NULL);

  // Variable graphic by file name:
  LLDefineVariableExt(job, "Graphic","sunny.bmp", LL_DRAWING, NULL);

  // Start printing:
  LlPrintWithBoxStart(job, LL_PROJECT_LABEL, szFile,
    LL_PRINT_EXPORT, LL_BOXTYPE_BRIDGEMETER, hWnd, "Printing...");

  //Print label:
  nErrorValue = LlPrint(job);

  // End printing:
  LlPrintEnd(job,0);
}

Private Sub ButtonPrint_Click()

  'Print the project "test.rpt" on the printer:
  Data1.Recordset.MoveFirst
  ListLabel1.Print(0, LL_PROJECT_LIST, "test.lst",_
    True, LL_PRINT_NORMAL,_
    LL_BOXTYPE_NORMALWAIT, hWnd,_
    "Print, True, Environ$("temp"))

End Sub

Private Sub ListLabel1_CmndDefineFields(ByVal nUserData As Long,
  ByVal bDummy As Long, nProgressInPerc As Long, pbLastRec As Long)

  'This event is called by the commands Print and Design.
  'It is called for each record to declare the fields and
  'their contents to List & Label.
  'Repeat for all fields of a 'record:
  For i = 0 To Form1.Data1.Recordset.Fields.Count - 1
    content$ = Data1.Recordset.Fields(i)
    nRet = ListLabel1.LlDefineFieldExt _
      (Data1.Recordset.Fields(i).Name,_
      content$, LL_TEXT)
  Next i
  'Skip to next record:
  Form1.Data1.Recordset.MoveNext
  'Stop printing of last record is reached:
  If Form1.Data1.Recordset.EOF = True Then
    pbLastRec = 1
  End If

End Sub
